| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Voltage Range | |
| Width |
The Mean Well USA RD-50B is a 54W enclosed switching power supply designed for various applications. It offers dual outputs with voltages of 5V on Channel 1 and 24V on Channel 2, providing rated currents of 6A and 1.4A respectively. The unit operates with a universal input voltage range of 88-264VAC and achieves an efficiency of 80% typical.
Key electrical specifications include adjustable output voltage ranges, line and load regulation, and hold-up times suitable for stable operation. Protection features such as overload and overvoltage protection are included, with overload protection operating in hiccup mode and recovering automatically. The power supply meets safety standards including UL60950-1 and TUV EN60950-1, and complies with EMC standards EN55022 Class B and EN61000-3-2,-3.
Mechanically, the RD-50B has dimensions of 99.0mm x 97.0mm x 36.0mm and is designed for chassis mounting. It operates within a temperature range of -25°C to 70°C and humidity range of 20% to 90% RH non-condensing. The MTBF is rated at a minimum of 172.6Khrs under specific conditions.
The RD-50B has dual outputs: 5V on Channel 1 and 24V on Channel 2.
Channel 1 provides a rated current of 6A, and Channel 2 provides 1.4A.
The RD-50B has a rated power output of 53.6W.
The RD-50B accepts a universal input voltage range of 88 to 264 VAC.
The RD-50B can operate in temperatures from -25°C to 70°C.
The dimensions of the RD-50B are 99.0mm in length, 97.0mm in width, and 36.0mm in height.
Yes, the RD-50B is RoHS3 Compliant.
