The Mean Well USA RCP-2000-48 is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It provides a robust 2016W of power with an output voltage of 3kV and a current rating of 42A.
Key electrical features include adjustable output, Power Factor Correction (PFC), remote on/off control, remote sense capability, and universal input. The converter operates efficiently with 92% efficiency and has a wide operating temperature range of -40°C to 70°C with derating.
Mechanically, this unit is designed for rack mounting and measures 295.0mm in length, 127.0mm in width, and 41.0mm in height. It has a single output and is approved by CB, CE, cURus, and TUV.
Environmental compliance includes RoHS3 compliance, MSL 1 (Unlimited) moisture sensitivity, and REACH unaffected status. This power supply is suitable for demanding commercial applications requiring reliable power conversion.
The RCP-2000-48 provides a single output of 48V at 42A.
The RCP-2000-48 is rated for 2016W of output power.
The RCP-2000-48 has a rated efficiency of 92%.
The RCP-2000-48 operates from -40°C to 70°C with derating.
The RCP-2000-48 is designed for rack mount installation.
Key features include adjustable output, power factor correction (PFC), remote on/off, remote sense, and universal input.
The RCP-2000-48 is approved by CB, CE, cURus, and TUV.
