Mfr Part #:

RCJ-412323

Name: RCJ-412323
Brand: CUI Devices
SKU: RCJ-412323

Mfr Name: CUI Devices

Description:

CONN RCA JACK QUAD 2X2 RED/WHT

Stock on Request

RCJ-412323 Description

Short technical summary and product information.

CONN RCA JACK QUAD 2X2 RED/WHT

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Category	Audio Connectors
Manufacturer Name	CUI Devices
Actual Diameter	0.142" (3.60mm ID), 0.327" (8.30mm OD)
Connector Type	Phono (RCA) Jack
Features	Board Lock
Gender	Female
Industry Recognized Mating Diameter	3.20mm ID, 9.00mm OD (RCA)
Insulation Color	Red, White
Internal Switch(s)	Does Not Contain Switch
Mounting Type	Through Hole, Right Angle
Number of Positions	2 Sets of 2 Conductors, 6 Contacts
Shielding	Unshielded
Signal Lines	Mono
Termination	Solder
