| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,675 pcs
|
6675 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
3,395 pcs
|
3395 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
55 pcs
|
55 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Features | |
| Height | |
| Length | |
| Number of Terminations | |
| Operating Temperature | |
| Power (Watts) | |
| Resistance | |
| Supplier Device Package | |
| Temperature Coefficient | |
| Tolerance | |
| Width |
The Yageo RC0805FR-07301RL is a surface mount chip resistor from the RC_L series, designed for general-purpose applications. It features a thick film composition and a standard 0805 (2012 Metric) package size.
Key electrical specifications include a resistance value of 301 Ohms with a tight tolerance of ±1%. The power rating is 1/8W (0.125W), and it offers a temperature coefficient of ±100ppm/°C. The operating temperature range spans from -55°C to 155°C.
Mechanically, the resistor measures 2.00mm in length and 1.25mm in width, with a height of 0.60mm. It has two terminations and is noted for its moisture resistance. The component is classified as MSL 1, indicating unlimited usability under standard conditions.
This component is suitable for various general-purpose applications where reliable resistance values and stable performance are required. Its surface mount design facilitates automated assembly processes.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.02 | $0.02 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 301 Ohms.
The tolerance is ±1%.
The power rating is 1/8W (0.125W).
The temperature coefficient is ±100ppm/°C.
The 0805 package measures 2.00mm in length, 1.25mm in width, and 0.60mm in height.
The operating temperature range is -55°C to 155°C.
