| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,387 pcs
|
4387 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
49 pcs
|
49 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Features | |
| Height | |
| Length | |
| Number of Terminations | |
| Operating Temperature | |
| Power (Watts) | |
| Resistance | |
| Supplier Device Package | |
| Temperature Coefficient | |
| Tolerance | |
| Width |
This Yageo RC0805FR-07267KL is a surface mount chip resistor designed for general-purpose applications. It features a resistance value of 267 kΩ with a tight tolerance of ±1% and a power rating of 0.125W (1/8W).
The resistor operates within a temperature range of -55°C to 155°C and has a temperature coefficient of ±100ppm/°C. Its thick film composition ensures reliability for various electronic circuits.
Packaged in the standard 0805 (2012 Metric) case size, it measures 2.00mm in length and 1.25mm in width, with a height of 0.60mm. The component has two terminations and is moisture resistant, with an MSL rating of 1.
This component is suitable for a wide range of general-purpose applications where precise resistance values and stable performance are required.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.02 | $0.02 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 267 kΩ.
The tolerance is ±1%.
The power rating is 0.125W, or 1/8W.
The temperature coefficient is ±100ppm/°C.
It operates from -55°C to 155°C.
The 0805 package measures 2.00mm in length, 1.25mm in width, and 0.60mm in height.
The MSL is 1.
