Mfr Part #:

RC0805FR-071ML

Mfr Name: Yageo

This Yageo RC0805FR-071ML is a 1 MΩ thick film chip resistor with a ±1% tolerance and a 1/8W power rating. It operates within a -55°C to 155°C temperature range.

✓ Total Stock: 135,744 pcs

$ Price Range: $0.02

RC0805FR-071ML Available from 9 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Fe Components ✓ Non-Authorised Inventory information	95,250 pcs On Request	95250 pcs	On Request	1	On Request	On Request	On Request	On Request	2026-04-08 17:15:04
Partservice ✓ Non-Authorised Inventory information	28,000 pcs On Request	28000 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Akira Global ✓ Non-Authorised Inventory information	5,600 pcs On Request	5600 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Speed Components Ltd ✓ Non-Authorised Inventory information	4,804 pcs On Request	4804 pcs	On Request	1	On Request	On Request	1633	On Request	On Request
Braun Electronic Components ✓ Non-Authorised Inventory information	920 pcs On Request	920 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
MW.FEP S.p.A. ✓ Non-Authorised Inventory information	739 pcs On Request	739 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Bristol Electronics ✓ Non-Authorised Inventory information	384 pcs On Request	384 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Trace Tec ✓ Non-Authorised Inventory information	46 pcs On Request	46 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
RAD ✓ Non-Authorised Inventory information	1 pcs On Request	1 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

RC0805FR-071ML Description

Short technical summary and product information.

The Yageo RC0805FR-071ML is a surface mount chip resistor from the RC_L series. It features a resistance value of 1 MΩ with a tight tolerance of ±1% and a power rating of 1/8W. The resistor is constructed using a thick film process and is designed for general-purpose applications.

With an operating temperature range of -55°C to 155°C and a temperature coefficient of ±100ppm/°C, this component offers reliable performance. Its dimensions are 2.00mm x 1.25mm (0.079" x 0.049") with a height of 0.60mm (0.024"), fitting the standard 0805 (2012 Metric) package size.

This component is RoHS3 compliant and has an MSL rating of 1, indicating unlimited usability under standard conditions. It is suitable for various electronic designs requiring precise resistance values in a compact surface mount form factor.

RC0805FR-071ML Quick Information

Product Type: Chip Resistor - Surface Mount

Series: RC_L

Canonical Name: Yageo RC0805FR-071ML 1 MΩ ±1% 1/8W 0805 Thick Film Surface Mount Resistor

Subcategory: Chip Resistor - Surface Mount

RC0805FR-071ML Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

RC0805FR-071ML Estimated Pricing

Qty	Low	High
1+	$0.02	$0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

RC0805FR-071ML Features

1 MΩ resistance with ±1% tolerance.
1/8W power rating for general applications.
Wide operating temperature range of -55°C to 155°C.
Compact 0805 (2012 Metric) surface mount package.
RoHS3 compliant and MSL 1 rated.

RC0805FR-071ML Applications

Suitable for general purpose circuits.
Ideal for automated PCB assembly.
Used in applications requiring stable resistance.
Component for compact electronic designs.

RC0805FR-071ML FAQs

6 frequently asked questions generated from this part’s specifications.

What is the resistance value of the RC0805FR-071ML resistor?

The resistance value is 1 MΩ.

What is the tolerance of the Yageo RC0805FR-071ML resistor?

The tolerance is ±1%.

What is the power rating for the RC0805FR-071ML?

The power rating is 1/8W (0.125W).

What is the operating temperature range for this chip resistor?

The operating temperature range is -55°C to 155°C.

What are the dimensions of the RC0805FR-071ML in millimeters?

The dimensions are 2.00mm in length and 1.25mm in width.

What is the package type for the RC0805FR-071ML?

The package type is 0805 (2012 Metric).

Category	Chip Resistor - Surface Mount
Manufacturer Name	Yageo
Composition	Thick Film
Features	Moisture Resistant
Height	0.60mm (0.024")
Length	2.00mm (0.079")
Number of Terminations	2
Operating Temperature	-55°C ~ 155°C
Power (Watts)	1/8W
Resistance	1 MΩ
Supplier Device Package	0805
Temperature Coefficient	±100ppm/°C
Tolerance	±1%
Width	1.25mm (0.049")
