RC0402JR-0791RL This Yageo RC0402JR-0791RL is a surface mount chip resistor with a resistance of 91 Ohms and a tolerance of ±5%. It has a power rating of 1/16W.
Mfr Part #:

RC0402JR-0791RL

Available from 2 distributors
Mfr Name: Yageo
Yageo
This Yageo RC0402JR-0791RL is a surface mount chip resistor with a resistance of 91 Ohms and a tolerance of ±5%. It has a power rating of 1/16W.
✓ Total Stock: 2 pcs
$ Price Range: $0.02

RC0402JR-0791RL Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
1 pcs
On Request
1 pcs On Request 1 On Request On Request On Request On Request On Request
RAD ✓
Non-Authorised Inventory information
1 pcs
On Request
1 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

RC0402JR-0791RL Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Composition
Features
Height
Length
Mounting Type
Number of Terminations
Operating Temperature
Power (Watts)
Resistance
Supplier Device Package
Temperature Coefficient
Tolerance
Width
View Similar Products (0)

RC0402JR-0791RL Description

Short technical summary and product information.

The Yageo RC0402JR-0791RL is a surface mount chip resistor from the RC_L series. It features a resistance value of 91 Ohms with a tolerance of ±5% and a power rating of 1/16W. The component operates within a temperature range of -55°C to 155°C and has a temperature coefficient of ±100ppm/°C.



Constructed with thick film technology, this resistor is housed in a 0402 (1005 Metric) package. Its dimensions are 1.00mm in length and 0.50mm in width, with a height of 0.40mm. The resistor has 2 terminations and is designed for general-purpose applications.



This component is RoHS3 compliant and has an MSL rating of 1, indicating unlimited moisture sensitivity. It is also REACH unaffected and features moisture resistance.

RC0402JR-0791RL Quick Information

Product Type: Chip Resistor
Series: RC_L
Canonical Name: Yageo RC0402JR-0791RL Chip Resistor
Subcategory: Surface Mount

RC0402JR-0791RL Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

RC0402JR-0791RL Estimated Pricing

Qty Low High
1+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

RC0402JR-0791RL Features

  • Surface mount chip resistor.
  • 91 Ohms resistance value.
  • ±5% tolerance rating.
  • 1/16W power rating.
  • 0402 package size.

RC0402JR-0791RL Applications

  • Used in high-density circuit boards
  • Suitable for signal filtering applications
  • Ideal for voltage divider networks
  • Applied in automotive and consumer electronics

RC0402JR-0791RL FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance value of the RC0402JR-0791RL?

The resistance value is 91 Ohms.

What is the tolerance of this resistor?

The tolerance is ±5%.

What is the power rating of the RC0402JR-0791RL?

The power rating is 1/16W (0.063W).

What is the operating temperature range?

The resistor operates from -55°C to 155°C.

What package size does this resistor use?

It uses a 0402 (1005 metric) package.

Is the resistor moisture resistant?

Yes, it features moisture resistant thick film construction.
