| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Power | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The RECOM Power RACM60-12SK/OF/2X4 is a versatile 60W AC/DC power supply module designed for industrial, household, and medical applications. It delivers a nominal output voltage of 12VDC with a maximum continuous output current of 5A, providing a total output power of 60W.
This converter operates from a wide input voltage range of 80-264VAC or 80-305VAC, ensuring compatibility with various power sources. It boasts a high efficiency of 90% typical at full load and nominal input. The unit is built with robust protection features including over-voltage, over-current, and short-circuit protection.
Designed for extended thermal performance, the RACM60-12SK/OF/2X4 operates across a temperature range of -40°C to +85°C with derating. Its open frame, chassis mount package measures 101.6mm x 53.0mm x 31.5mm, making it suitable for space-constrained systems. The module is certified to medical safety standards like ANSI/AAMI ES60601-1 and EN 60601-1-2, as well as IEC/EN62368-1 and IEC61558-1/-2-16 for industrial use and IEC/EN60335-1 for household appliances.
Key features include 4kVAC isolation, a built-in Class B EMC filter, and a 3-year warranty. This model is suitable for applications requiring high reliability and compliance with stringent safety and EMC standards.
The input voltage range is 80-264 VAC or 80-305 VAC depending on operating condition.
The package is open frame with chassis mount, package code XMA, rectangular shape.
The operating temperature range is -40°C to 85°C with derating.
The output voltage is 12 VDC nominal.
The output current is 5 A nominal.
Typical efficiency is 90% at 230VAC full load and 25°C.
The isolation voltage is 4 kVAC for 1 minute.
