| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage | |
| Width |
The RACM40-24S from Recom Power is a 40 Watt AC/DC power supply designed for medical applications, offering 2xMOPP safety approval. It operates with a universal input voltage range of 85-264VAC and provides a stable 24VDC output.
This converter boasts a high efficiency of 92% and a low leakage current of less than 75µA. It is suitable for built-in Class II applications and can operate at altitudes up to 5000m. The operating temperature range is -40°C to +85°C, with derating applied.
Designed for versatility, the RACM40-24S features adjustable output voltage trimming of ±10% and requires no minimum load. Its compact dimensions and chassis mount type make it suitable for integration into various systems. The unit also includes 4kVAC isolation and a 5-year warranty.
-40°C to +85°C with derating.
85-264VAC AC or 100-370VDC DC.
24VDC at 1.67A, 40W.
92% typical.
4kVAC.
Enclosed chassis mount.
No, minimum load is 0%.
