The RECOM Power RAC40-15SA-E is a 40W AC/DC power supply designed for reliable operation. It accepts a universal input voltage range of 90-264 VAC and provides a single 15V output at up to 2.67A.
Key electrical specifications include an efficiency of 83%, line regulation of ±0.5%, and load regulation of ±1%. The converter offers 4000VAC isolation and features short circuit and overcurrent protection. It operates within a temperature range of -40°C to +70°C with derating.
This AC/DC converter is housed in a 7-DIP Module, 5 Leads package and is designed for Through Hole mounting. It is certified by CE and cULus, making it suitable for medical applications. The unit is RoHS3 Compliant.
With its compact size (89.0mm x 63.5mm x 27.5mm) and robust features, the RAC40-15SA-E is a versatile power solution for various industrial and medical equipment.
AC input: 90-264 VAC; DC input: 100-370 VDC.
The output is 15V DC at 2.67A maximum.
The operating temperature range is -40°C to +70°C with derating.
7-DIP Module, 5 Leads, through-hole mounting.
Short circuit protection (continuous, automatic restart), overcurrent protection at 105% typical, and over temperature protection at 100°C.
83% typical.
89.0mm x 63.5mm x 27.5mm (3.50" x 2.50" x 1.08").
