The Recom RAC20-12SB-ST is an enclosed, chassis mount AC/DC power supply from the RAC20-B series. It delivers a 12V output at 1.66A, providing a total power of 20W. The unit accepts a wide input voltage range of 90V AC to 264V AC, making it suitable for global applications.
Key electrical specifications include an efficiency of 82% and 3kVac isolation. The operating temperature range is -40°C to 70°C with derating. Its dimensions are 96mm in length, 53.9mm in width, and 29.1mm in height, with a weight of 59g.
This power supply is designed for ITE (Commercial) applications and features a single output. It is RoHS3 compliant and has an MSL of 1 Unlimited. A DIN-Rail mounting kit is available separately.
90 to 264 VAC.
12V at 1.66A.
-40°C to 70°C.
Chassis mount.
82%.
3kVac.
96.0mm x 53.9mm x 29.1mm.
