This Recom Power RAC150-48SG/OF is an AC/DC converter designed for various applications. It delivers up to 150W of power with a 48V output voltage and a typical output current of 3.125A. The converter operates with a wide input voltage range from 90V ac to 264V ac, making it suitable for global use.
With an efficiency rating of 91%, this power supply minimizes energy waste. It features an open frame package, which aids in airflow and thermal management. The unit includes built-in overvoltage and short-circuit protection for enhanced reliability and automatic restarts after faults. Its compact dimensions of 101.6mm x 50.8mm x 30.0mm allow for flexible integration into systems.
Key specifications include a minimum operating temperature of -30°C and a maximum of 70°C with derating. It also has a line regulation of ±0.1% and supports a maximum capacitive load of 500μF. The converter is certified to various standards including CB, CE, cURus, and EAC, and is RoHS3 compliant.
Applications for this power supply include ITE (Commercial) equipment, schools, offices, surveillance systems, and packing plants.
The maximum output voltage is 48V.
The typical SMPS output current is 3.13A.
It provides 125W typical power and 150W with forced air.
The input voltage range is from 90V ac to 264V ac.
The typical efficiency is 91%.
The operating temperature range is -30°C to 70°C with derating.
The dimensions are 101.6mm in length, 50.8mm in width, and 30.0mm in height.
