| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Maximum Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Recom RAC150-48SG/ENC is a 150W enclosed AC DC power supply designed for high-power density applications. It features a universal input voltage range of 90V ac to 264V ac and provides a regulated 48V DC output.
Key specifications include an output current of 3.125A, 91% efficiency, and a wide operating temperature range of -30°C to 70°C with derating. The unit is chassis mounted and has dimensions of 105.0mm x 62.0mm x 35.0mm.
This power supply is suitable for ITE (Commercial) applications and meets various safety standards including IEC 60950-1 and UL 60950-1. It also features active Power Factor Correction (PFC).
Compliance includes RoHS3, REACH Unaffected, and MSL 1. The RAC150-48SG/ENC is designed for reliable performance in industrial control and test and measurement environments.
The Recom RAC150-48SG/ENC has an output voltage of 48V.
The power rating is 150W.
The operating temperature range is -30°C to 70°C with derating.
The dimensions are 105.0mm x 62.0mm x 35.0mm.
The efficiency is 91%.
It complies with IEC 60950-1, CAN/CSA C22.2 No. 60950-1-07, EN 55022 Class B, EN 55024, EN 60950-1, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, RoHS, and UL 60950-1.
