| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Storage Temperature | |
| Type | |
| Voltage |
The RECOM Power RAC15-15DA is a 15 Watt AC/DC converter designed for ITE (Commercial) applications. It offers a universal input voltage range of 90-264 VAC and provides a dual output of ±15V at 500mA per output.
Key electrical specifications include an efficiency of 77%, 3000VAC isolation, and ±2% output voltage accuracy. The converter is protected against short circuits with a hiccup mode and automatic restart.
This AC/DC converter is housed in an 8-DIP Module package and is designed for Through Hole mounting. It operates within a temperature range of -25°C to 70°C with derating and has a storage temperature range of -40°C to 85°C.
The RAC15-15DA series is UL Certified and CE Marked, ensuring compliance with relevant safety standards.
The input voltage range is 90-264 VAC or 120-370 VDC.
It provides ±15 VDC at ±500 mA.
The standard operating temperature range is -25°C to 70°C (with derating). An extended temperature version offers -40°C to 70°C.
It comes in an 8-DIP Module with 6 leads, through-hole mounting.
The input-to-output isolation is 3000 VAC.
Yes, it features hiccup mode short circuit protection with automatic restart.
Typical efficiency is 77%.
