| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The RECOM RAC10-05SB-E-ST is a 10 Watt AC/DC power supply designed for PCB mounting. It provides a regulated 5V output at 2A, with a rated power of 10W. The converter features a universal input voltage range of 90-264 VAC, making it suitable for global applications.
Key electrical specifications include an efficiency of 72%, ±2% output voltage accuracy, and ±0.3% typical line voltage regulation. It offers 3kVAC isolation between input and output and includes automatic restart short circuit protection. The operating temperature range is -40°C to +70°C with derating.
Designed for ITE (Commercial) applications, this enclosed converter has a chassis mount type. Its dimensions are 96.0mm x 53.9mm x 29.1mm. The series is part of RECOM's POWERLINE RAC10-B family.
Compliance includes CE and cURus approvals. The RoHS status is RoHS3 Compliant.
90-264 VAC or 120-370 VDC.
5 VDC at 2 A.
-40°C to +70°C with derating.
Chassis mount, 96.0 x 53.9 x 29.1 mm.
3 kVAC input to output.
Short circuit protection with hiccup and automatic restart.
72%.
