| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Reset Time | |
| SVHC Present | |
| Voltage Rating |
The NTE Electronics R59-5A is a thermal circuit breaker designed for reliable overcurrent protection. It features a 5A current rating and can handle up to 250 VAC or 32 VDC.
This circuit breaker is built with a thermal tripping mechanism, ensuring it will continuously carry 100% of its rated current. For 3.0 to 20 Amp types, it may trip between 101% and 134% of rating but must trip at 135% within one hour at 25°C. The interrupt capacity is rated at 1000A for both 250 VAC and 32 VDC.
Designed for easy integration, the R59-5A features a panel mount, snap-in mounting type and a rocker actuator. Its dielectric strength is 1500 VAC RMS. The reset time for this 5A type is typically between 10 to 60 seconds.
This component is suitable for various applications requiring robust circuit protection, offering dependable performance and a compact design for panel installations.
The NTE R59-5A circuit breaker has a current rating of 5A.
The NTE R59-5A circuit breaker is rated for 250 VAC and 32 VDC.
The NTE R59-5A is a thermal circuit breaker.
The NTE R59-5A circuit breaker is designed for panel mount, snap-in installation.
The interrupt capacity is 1000A at 250 VAC, 50/60 Hz, and 32 VDC.
For 3.0 to 20 Amp types, the reset time is typically 10 to 60 seconds.
