| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating |
The NTE Electronics R59-15A is a thermal circuit breaker with a 15A current rating, suitable for applications requiring protection up to 250V AC or 50V DC. This circuit breaker is designed for easy panel mounting with a snap-in configuration, simplifying installation in various enclosures.
Key electrical specifications include a 15A current rating and dual voltage support for both AC and DC circuits. The thermal tripping mechanism provides reliable overcurrent protection. The actuator type is a push-to-reset button, allowing for manual reset after a trip event. It is a single-pole device, indicated by the 'Number of Poles' attribute.
This component is approved by CSA and UR agencies, signifying its compliance with relevant safety standards. The RoHS status is listed as RoHS3 Compliant, and the Moisture Sensitivity Level (MSL) is 1, indicating unlimited shelf life under standard conditions. The REACH status is noted as REACH Unaffected.
Designed for straightforward integration, the R59-15A circuit breaker is a practical choice for protecting electrical circuits from overloads and short circuits in a wide range of equipment and systems.
The R59-15A circuit breaker has a current rating of 15A.
The R59-15A circuit breaker is rated for 250V AC and 50V DC.
The R59-15A circuit breaker is designed for panel mounting and features a snap-in installation method.
The R59-15A circuit breaker uses a push-to-reset actuator.
The R59-15A circuit breaker is approved by CSA and UR.
The R59-15A circuit breaker is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) for the R59-15A circuit breaker is 1 Unlimited.
