| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Termination Style | |
| Voltage Rating | |
| Weight |
This NTE Electronics R58-35A is a thermal circuit breaker designed for reliable circuit protection. It features a 35A current rating and can handle up to 250 VAC or 50 VDC.
The breaker type is thermal, with a pushbutton actuator for operation. It is a single-pole unit designed for panel mounting, utilizing quick connect terminals for termination.
Key electrical specifications include a dielectric strength of 1500 VAC RMS and an interrupt capacity of 2000 Amps at 50 VDC and 1000 Amps at 250 VAC. The unit is built to withstand mechanical stress, with shock resistance up to 10 g and vibration resistance up to 10 g at 10 to 55 Hz. Endurance cycling is rated for over 1000 cycles at 200% of rated load.
Compliance includes RoHS3, MSL 1, and REACH Unaffected status. The device weighs less than 1.5 oz.
250VAC and 50VDC.
Panel mount with quick connect terminals.
2000A at 50VDC and 1000A at 250VAC.
Pushbutton.
Will continuously carry 100% of rating, may trip between 101% and 144%, must trip at 145% at +25°C.
1500VAC RMS.
Less than 1.5 oz (42.5 g).
