The Radiall R573403600 is a high-performance SP6T (Single Pole, Six Throw) RF switch. It features a frequency range of 0 to 18 GHz and a standard impedance of 50 Ohms, making it suitable for a wide array of RF applications.
This switch is designed with SMA female connectors and a splashproof construction for enhanced durability. The actuator operates normally open with a voltage range of 24V to 30VDC, consuming a nominal current of 102 mA. It offers a minimum isolation of 60 dB and a maximum insertion loss of 0.5 dB at 18 GHz.
With a switching time of less than 15 ms and a mechanical life of 5 million cycles per position, the R573403600 is built for reliability. The operating temperature range is -40°C to +85°C, ensuring performance in various environmental conditions. Terminals are solder pins, rated for 250°C maximum for 30 seconds.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The frequency range is 0 to 18 GHz.
The impedance is 50 Ohms.
The actuator operates between 24V and 30VDC.
The operating temperature range is -40°C to +85°C.
The minimum isolation is 60 dB.
The maximum insertion loss is 0.5 dB.
It uses SMA female connectors.
