R404155000 Radiall R404155000 is an SMB female termination with 50Ω impedance, operating from DC to 8 GHz. It handles 0.5W average power and features low VSWR.
Mfr Part #:

R404155000

Available from 1 distributors
Mfr Name: Radiall
Radiall
Radiall R404155000 is an SMB female termination with 50Ω impedance, operating from DC to 8 GHz. It handles 0.5W average power and features low VSWR.
✓ Total Stock: 181 pcs
$ Price Range: $245.51

R404155000 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
181 pcs
On Request
181 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

R404155000 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Approval Agency
Body Material
Connector Style
Connector Type
Contact Finish
Contact Material
DC Resistance
Features
Frequency
Frequency Range
Impedance
Insulator Material
Lead Style
Mounting Type
Operating Temperature Range
Storage Temperature
Tape & Reel
Termination Style
Weight
View Similar Products (0)

R404155000 Description

Short technical summary and product information.

The Radiall R404155000 is a 50-ohm SMB female termination designed for RF applications up to 8 GHz. It features a free-hanging, cap-style mounting with a female socket connector.



The termination offers a DC resistance of 50Ω ±5% and an impedance of 50Ω. VSWR is specified as 1.10 maximum from DC to 2 GHz, 1.20 from 2 to 4 GHz, and 1.25 from 4 to 8 GHz. Average power rating is 0.5W in free air at 25°C, with peak power handling of 100W under 1µs pulse, 1% duty cycle.



The body is made of ARCAP AP1D, center contact of beryllium copper with gold plating, and insulator of PTFE. It weighs 3.8 grams and operates over -55°C to +125°C. The termination includes a cord feature.



The part is listed as RoHS3 compliant and REACH unaffected, though these are unverified. MSL is 1 (unlimited).

R404155000 Quick Information

Product Type: Coaxial Connector (RF) Terminator
Canonical Name: SMB Female Termination, 50 Ohms, DC to 8 GHz, 0.5 W
Subcategory: SMB Female Termination

R404155000 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

R404155000 Estimated Pricing

Qty Low High
10+ $245.51 $245.51

Estimated market price range - modelled values for guidance only, not live distributor offers.

R404155000 Features

  • 50Ω impedance for RF termination applications.
  • Frequency range DC to 8 GHz.
  • Low VSWR: 1.10 max from DC to 2 GHz.
  • Gold-plated beryllium copper contacts.
  • Free-hanging cap mounting style.

R404155000 Applications

  • Terminating unused RF ports on test equipment.
  • Impedance matching in coaxial transmission lines.
  • Used in RF system calibration and testing.
  • Suitable for low-power RF signal termination.

R404155000 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the impedance of the R404155000?

50Ω.

What is the frequency range?

DC to 8 GHz.

What is the VSWR?

VSWR is 1.10 max from DC to 2 GHz, 1.20 from 2 to 4 GHz, and 1.25 from 4 to 8 GHz.

What is the power handling?

Average power 0.5W in free air at 25°C, peak power 100W (1µs pulse, 1% duty).

What is the mounting type?

Free hanging, cap.

What is the operating temperature range?

-55°C to +125°C.

What connector type does it have?

SMB plug, female socket.
