| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Voltage | |
| Contact Form | |
| Contact Rating (Current) | |
| Mounting Type | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Termination Style |
This NTE Electronics R14-11D10-24F is a general purpose relay designed for various applications. It features a DPDT (2 Form C) contact configuration, capable of handling a current rating of 15A. The relay operates with a 24VDC coil voltage.
With an operating temperature range of -30°C to 55°C, this relay is suitable for a variety of environmental conditions. The termination style is Plug In, Quick Connect - 0.187" (4.7mm), facilitating easy integration into systems. The operate and release times are both rated at 25 ms, ensuring responsive switching.
This component is part of the R14 series and is categorized under Power Relays, Over 2 Amps. Its general-purpose nature makes it a versatile choice for many electrical control and switching tasks.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The coil voltage for the R14-11D10-24F relay is 24VDC.
The R14-11D10-24F relay has a DPDT (2 Form C) contact form.
The R14-11D10-24F relay has a contact rating of 15A.
The operating temperature range for the R14-11D10-24F relay is -30°C to 55°C.
The termination style for the R14-11D10-24F relay is Plug In, Quick Connect - 0.187" (4.7mm).
