| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Voltage | |
| Contact Form | |
| Contact Rating (Current) | |
| Lead Spacing | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Termination Style |
The R14-11D10-12F from NTE Electronics is a general purpose power relay designed for applications requiring robust switching capabilities. It features a DPDT (2 Form C) contact configuration, allowing for versatile circuit control.
This relay is rated for a continuous current of 15A and is operated by a 12VDC coil. The operating temperature range is specified from -30°C to 55°C, making it suitable for a variety of environmental conditions. Both the operate and release times are a swift 25 ms, ensuring efficient switching performance.
The termination style is Plug In, with Quick Connect terminals measuring 0.187" (4.7mm), facilitating easy and secure connections in system assemblies. The RoHS status is listed as RoHS3 Compliant, and the Moisture Sensitivity Level (MSL) is 1 Unlimited, indicating standard handling requirements.
This power relay is an ideal component for industrial control systems, power distribution units, and other applications where reliable and high-current switching is essential.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The coil voltage for the R14-11D10-12F relay is 12VDC.
The R14-11D10-12F power relay has a DPDT (2 Form C) contact form.
The R14-11D10-12F relay is rated for 15A.
The R14-11D10-12F relay operates between -30°C and 55°C.
The R14-11D10-12F relay is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) for the R14-11D10-12F relay is 1 Unlimited.
