| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Contact Resistance | |
| Insulation Resistance | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Termination Style | |
| Weight |
This NTE Electronics R14-11A10-12F is a general purpose relay featuring a DPDT (2 Form C) contact arrangement. It is rated for a maximum contact current of 15A at 150VAC/30VDC and can handle loads up to 1/3 HP at 120VAC or 1/2 HP at 240VAC. The relay operates with a 12VAC coil voltage and has a coil power rating of 1.2VA.
Key electrical specifications include a contact resistance of 100 milliohms maximum and operate/release times of 25ms or less. Insulation characteristics include a dielectric strength of 1500 VRMS between contact and coil, and 1000 VRMS across open contacts. The operating temperature range is -30°C to +55°C.
The relay features plug-in termination with 0.187" (4.7mm) quick connect terminals. It is designed for high reliability with a rated life of 50 million operations. This flange mount version is slightly larger than one cubic inch.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The R14-11A10-12F relay has a contact rating of 15A at 150VAC/30VDC, 10A at 240VAC, and 1/3 HP at 120VAC or 1/2 HP at 240VAC.
The coil voltage for the R14-11A10-12F relay is 12VAC.
The R14-11A10-12F relay has a DPDT (2 Form C) contact form.
The operating temperature range for the R14-11A10-12F relay is -30°C to +55°C.
The operate and release times for the R14-11A10-12F relay are 25ms or less.
