| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Contact Resistance | |
| Insulation Resistance | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Termination Style | |
| Weight |
The NTE Electronics R14-11A10-120 is a general purpose DPDT relay designed for reliable switching applications. It offers a robust 15 Amp contact rating at 120VAC and is operated by a 120VAC coil.
Key electrical specifications include a 25 ms operate time and a 25 ms release time, ensuring efficient operation. The relay is constructed with silver cadmium oxide contacts and has a contact resistance of 100 milliohms maximum. It is rated for continuous duty cycle.
Environmental considerations include an operating temperature range of -30°C to 55°C. The termination style is plug-in with 0.187" (4.7mm) quick connect terminals, facilitating straightforward integration into systems. The relay has a weight of approximately 1.5 oz (45 grams).
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The R14-11A10-120 relay has a DPDT (2 Form C) contact form.
The R14-11A10-120 relay has a maximum current rating of 15 A.
The coil voltage for the R14-11A10-120 relay is 120 VAC.
The operating temperature range for this relay is -30°C to 55°C.
The R14-11A10-120 relay uses plug-in, quick connect terminals measuring 0.187" (4.7mm).
The operate time is 25 ms or less, and the release time is 25 ms or less.
