ADT-8000-MF-SMA-02
Cinch
SMA to SMA right angle adapter with plug (male) to jack (female) configuration. 50 Ohm impedance, DC to 18 GHz, gold plated center contact.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adapter Series | |
| Adapter Type | |
| Center Contact Plating | |
| Center Gender | |
| Conversion Type | |
| Convert From (Adapter End) | |
| Convert To (Adapter End) | |
| Fastening Type | |
| Frequency | |
| Impedance | |
| Mounting Type | |
| Style |
The Radiall R125771000 is a coaxial adapter designed for SMA series connectors. It converts an SMA plug (male pin) to an SMA jack (female socket) with a right angle orientation, making it suitable for space-constrained RF applications. The adapter offers a 50 Ohm impedance and supports frequencies up to 18 GHz, ensuring signal integrity in high-frequency environments.
Mechanically, the R125771000 features free hanging (in-line) mounting with a right angle style. Both ends use threaded coupling for secure and repeatable connections. The center contacts are gold plated, providing excellent conductivity and corrosion resistance. The adapter is designed for plug-to-jack conversion within the same SMA series.
This adapter is commonly used in test and measurement setups, telecommunications infrastructure, and microwave communication systems where a compact, reliable RF interconnection is required. The gold-plated contacts and 50 Ohm matched impedance help minimize signal loss and reflections.
| Qty | Low | High |
|---|---|---|
| 1+ | $65.78 | $65.78 |
| 10+ | $55.91 | $55.91 |
| 25+ | $52.41 | $52.41 |
| 50+ | $49.91 | $49.91 |
| 100+ | $47.53 | $47.53 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Free Hanging (In-Line), Right Angle.
50 Ohm.
18 GHz.
SMA to SMA.
Female to Male.
Threaded on both ends.
Yes, RoHS3 Compliant (unverified).
