| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Center Contact Material | |
| Connector Style | |
| Connector Type | |
| Contact Termination | |
| Fastening Type | |
| Frequency | |
| Housing Color | |
| Impedance | |
| Mounting Type | |
| Number of Ports | |
| Shield Termination |
The R125556001 from Radiall is an SMA coaxial connector receptacle with a female socket. It features a panel mount design with threaded fastening for secure installation. The contact and shield are terminated via solder, ensuring reliable electrical connections. The center contact is made of beryllium copper, providing good conductivity and durability.
This connector is rated for 50 Ohm impedance and supports frequencies up to 18 GHz, making it suitable for RF and microwave applications. The housing has a silver color finish. It is a single-port device.
The connector is designed for panel mounting with a threaded interface. It is RoHS3 compliant and REACH unaffected, though these compliance statuses are unverified. The part is categorized under Coaxial Connector (RF) Assemblies.
| Qty | Low | High |
|---|---|---|
| 10+ | $49.28 | $49.28 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Panel mount with threaded fastening.
50 Ohm.
18 GHz.
SMA receptacle with female socket.
Solder.
Beryllium copper.
1 port.
