| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Group | |
| Center Contact Material | |
| Connector Style | |
| Connector Type | |
| Contact Termination | |
| Fastening Type | |
| Frequency | |
| Housing Color | |
| Impedance | |
| Mounting Feature | |
| Mounting Type | |
| Number of Ports | |
| Shield Termination | |
| Termination Style |
The Radiall R125326000W is an SMA coaxial connector designed as a female socket jack. It is configured for panel mounting with a bulkhead front side nut feature, ensuring secure installation in panels. The connector uses threaded fastening for mating. Electrically, it offers a 50 Ohm impedance and supports frequencies up to 18 GHz, making it suitable for high-frequency RF applications. The connector has a single port and uses solder terminations for both center contact and shield. The center contact is made of beryllium copper, providing good conductivity and durability. The housing is gold in color. This connector is designed for use with cable group RG-405 (.085" semi-rigid). Environmental compliance includes RoHS3 (unverified), MSL 1 unlimited, and REACH unaffected. The connector is a coaxial RF connector assembly, ideal for use in telecommunications, test equipment, and other RF systems requiring a reliable SMA bulkhead interface.
| Qty | Low | High |
|---|---|---|
| 10+ | $36.11 | $36.11 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Jack, Female Socket.
SMA (SubMiniature version A) connector.
Panel mount with bulkhead front side nut.
50 Ohm.
18 GHz.
Solder termination for both contact and shield.
Beryllium Copper.
