| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Resistance | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Contact Resistance | |
| Duty Cycle | |
| Insulation Resistance | |
| Mounting Type | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Termination Style | |
| Weight |
This NTE Electronics R12-17D3-12 is a general purpose relay designed for reliable switching applications. It features a 4PDT contact arrangement capable of handling up to 5 Amps at 240VAC/28VDC.
The relay operates with a 12VDC coil voltage and has a coil resistance of 160 Ohms, consuming approximately 0.9W of power. Electrical specifications include contact ratings of 5A, 3A, and 1A at 240VAC/28VDC, with contact material options of silver cad-oxide or silver with gold flashing for the T-type.
Operational characteristics include an operate and release time of 25ms or less. The relay is designed for a wide operating temperature range of -30°C to +55°C. Insulation characteristics include dielectric strength ratings for contact-to-coil, across open contacts, and coil-to-frame, along with a minimum insulation resistance of 100 megohms.
Available with plug-in or solder terminal styles, this relay is suitable for PC board mounting. It weighs approximately 1.5 oz (45 grams) and offers high reliability with a rated lifespan of 50 million operations.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The R12-17D3-12 relay features a 4PDT (4 Form C) contact arrangement.
The R12-17D3-12 relay has a maximum contact rating of 5 Amp @ 240VAC/28VDC.
The coil voltage for the R12-17D3-12 relay is 12VDC.
The R12-17D3-12 relay has an operate time of 25ms or less and a release time of 25ms or less.
The R12-17D3-12 relay operates within a temperature range of -30°C to +55°C.
