R12-11A5-24 The NTE Electronics R12-11A5-24 is a general purpose relay with a DPDT contact form and a 5A contact rating. It operates on a 24VAC coil voltage.
Mfr Part #:

R12-11A5-24

Available from 1 distributors
Mfr Name: NTE Electronics
NTE Electronics
The NTE Electronics R12-11A5-24 is a general purpose relay with a DPDT contact form and a 5A contact rating. It operates on a 24VAC coil voltage.
✓ Total Stock: 2 pcs
$ Price Range: $2.00

R12-11A5-24 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
2 pcs
On Request
2 pcs On Request 1 On Request On Request 2026-02-25 06:16:38 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

R12-11A5-24 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Coil Voltage
Contact Form
Contact Rating (Current)
Contact Resistance
Insulation Resistance
Operate Time
Operating Temperature
Relay Type
Release Time
Termination Style
Weight
View Similar Products (0)

R12-11A5-24 Description

Short technical summary and product information.

This NTE Electronics R12-11A5-24 is a general purpose relay designed for reliable switching applications. It features a DPDT (2 Form C) contact arrangement capable of handling up to 5 Amps at 240VAC/28VDC. The relay is operated by a 24VAC coil and offers a nominal coil power of 1.2VA.



With an operate and release time of 25ms or less, this relay is suitable for applications requiring timely switching. It operates within an environmental temperature range of -30°C to +55°C. The termination style is plug-in, facilitating easy installation and maintenance in various systems.



Electrical specifications include a contact resistance of 100 milliohms maximum at 6VDC, 1A. Insulation characteristics are robust, with dielectric strength ratings of 1500 VRMS between contact and coil, 1000 VRMS across open contacts, and 1500 VRMS from coil to frame. Insulation resistance is a minimum of 100 megohms at 500VDC.



The relay has a weight of approximately 45 grams (1.5 ozs). Its features include a see-thru plastic cover and it is slightly larger than one cubic inch. This model is part of the R12 series from NTE Electronics.

R12-11A5-24 Quick Information

Product Type: General Purpose Relay
Canonical Name: NTE Electronics R12-11A5-24 General Purpose Relay
Subcategory: Power Relay

R12-11A5-24 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

R12-11A5-24 Estimated Pricing

Qty Low High
1+ $2.00 $2.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

R12-11A5-24 Features

  • DPDT contact form for versatile switching.
  • Rated for 5A at 240VAC/28VDC.
  • Operates on a 24VAC coil voltage.
  • Fast operate and release times of 25ms.
  • Plug-in termination style for convenience.

R12-11A5-24 Applications

  • Suitable for general purpose switching.
  • Used in control system applications.
  • Ideal for automation equipment.
  • Applicable in industrial controls.

R12-11A5-24 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the coil voltage for the R12-11A5-24 relay?

The coil voltage for the R12-11A5-24 relay is 24VAC.

What is the contact rating of the R12-11A5-24 relay?

The contact rating is 5A at 240VAC/28VDC.

What type of contact form does the R12-11A5-24 relay have?

The R12-11A5-24 relay has a DPDT (2 Form C) contact form.

What is the operating temperature range for this relay?

The operating temperature range is -30°C to +55°C.

What are the operate and release times for the R12-11A5-24 relay?

The operate and release times are both 25ms or less.
