R114005133W The Radiall R114005133W is an SMB straight plug coaxial connector assembly. It offers a 4 GHz maximum frequency and 50 Ohm impedance.
Mfr Part #:

R114005133W

Available from 1 distributors
Mfr Name: Radiall
Radiall
The Radiall R114005133W is an SMB straight plug coaxial connector assembly. It offers a 4 GHz maximum frequency and 50 Ohm impedance.
✓ Total Stock: 20 pcs
$ Price Range: $1.00

R114005133W Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Chanetech ✓
Non-Authorised Inventory information
20 pcs
On Request
20 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

R114005133W Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Cable Group
Center Contact Material
Connector Style
Connector Type
Contact Termination
Fastening Type
Frequency
Housing Color
Impedance
Mounting Type
Number of Ports
Shield Termination
Termination Style
View Similar Products (0)

R114005133W Description

Short technical summary and product information.

This Radiall R114005133W is a coaxial connector assembly featuring an SMB straight plug with a female socket. It is designed for free-hanging (in-line) mounting and utilizes a snap-on fastening type. The connector operates at a maximum frequency of 4 GHz and maintains a characteristic impedance of 50 Ohms.



The center contact is made of Beryllium Copper, and the housing is finished in gold for durability and conductivity. The shield termination is a clamp type, and the contact termination is solder. This assembly is suitable for cable groups including RG-179, RG-187, RG-188, and RG-316.



With a single port and a gold housing color, this connector is built for reliable RF signal transmission. Its construction and specifications make it suitable for various RF applications where a secure and stable connection is required.

R114005133W Quick Information

Product Type: Coaxial Connector (RF) Assembly
Canonical Name: Radiall R114005133W SMB Straight Plug, Female Socket
Subcategory: RF Assembly

R114005133W Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

R114005133W Estimated Pricing

Qty Low High
1+ $1.00 $1.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

R114005133W Features

  • SMB straight plug, female socket connector.
  • Operates at a 4 GHz maximum frequency.
  • Features 50 Ohm impedance.
  • Free hanging, in-line mounting type.
  • Snap-on fastening for secure connection.

R114005133W Applications

  • Suitable for RF signal transmission.
  • Used in coaxial cable assemblies.
  • Ideal for free-hanging installations.
  • Compatible with specific RG cable groups.

R114005133W FAQs

7 frequently asked questions generated from this part’s specifications.
What is the impedance of the R114005133W connector?

The impedance is 50 Ohms.

What frequency does the R114005133W support?

It supports up to 4 GHz frequency.

What is the connector style of the R114005133W?

It has an SMB connector style.

What is the mounting type of this connector?

It is a free hanging (in-line) mounting type.

What is the contact termination method?

The contact termination is solder.

What material is used for the center contact?

The center contact is made from beryllium copper.

What is the shield termination type?

The shield termination is clamp.
