QTH-060-07-L-D-A .5mm High-Speed Ground Plane SMT Header Connector by Samtec, 120 pin, 2 row, 0.50mm pitch, gold plating, 25mm stacking height.
Mfr Part #:

QTH-060-07-L-D-A

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
.5mm High-Speed Ground Plane SMT Header Connector by Samtec, 120 pin, 2 row, 0.50mm pitch, gold plating, 25mm stacking height.
✓ Total Stock: 1 pcs
$ Price Range: $10.18 - $18.15

QTH-060-07-L-D-A Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
1 pcs
On Request
1 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

QTH-060-07-L-D-A Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Connector Type
Contact Finish
Contact Finish Thickness
Contact Material
Features
Halogen Free
Height Above Board
Industrial Grade
Insulator Material
Lead Style
Mated Stacking Heights
Medical Grade
Military Grade
Mounting Type
Number of Positions
Number of Rows
Operating Temperature Range
Pitch
SVHC Present
Tape & Reel
Voltage Rating
View Similar Products (0)

QTH-060-07-L-D-A Description

Short technical summary and product information.

The Samtec QTH-060-07-L-D-A is a high-speed ground plane SMT header connector from the QTH series. It features 120 positions arranged in 2 rows at a 0.50mm pitch. The connector is designed for surface mount soldering and includes a board guide and ground bus plane for enhanced performance.



Key electrical specifications include a contact current rating of 2 A per pin (2 pins powered) and a ground plane current rating of 25 A per ground plane. The voltage rating is 175 VAC at 5 mm stack height. The operating temperature range covers -55 °C to +125 °C.



The connector uses a liquid crystal polymer insulator and phosphor bronze contacts with 10 µ" gold on contact and matte tin on tail. The mated stacking height is 25mm. This component is supplied in tray packaging with a standard quantity of 36 pieces.

QTH-060-07-L-D-A Quick Information

Product Type: Header, Outer Shroud Contacts
Series: QTH
Canonical Name: QTH-060-07-L-D-A .5mm High-Speed Ground Plane SMT Header Connector
Subcategory: Arrays, Edge Type, Mezzanine (Board to Board)

QTH-060-07-L-D-A Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: No

QTH-060-07-L-D-A Estimated Pricing

Qty Low High
1+ $18.15 $18.15
10+ $17.61 $17.61
25+ $17.16 $17.16
50+ $16.33 $16.33
100+ $13.93 $13.93
250+ $11.87 $11.87
500+ $10.18 $10.18

Estimated market price range - modelled values for guidance only, not live distributor offers.

QTH-060-07-L-D-A Features

  • 120 position, 2 row, 0.50mm pitch connector.
  • Gold plated contacts with 10 µ" thickness.
  • Rated for 2 A per contact pin.
  • Operating temperature range -55 °C to +125 °C.
  • SMT mounting with board guide and ground plane.

QTH-060-07-L-D-A Applications

  • High-speed board-to-board mezzanine connections.
  • Differential pair signal routing.
  • Ground plane distribution in dense PCBs.
  • Applications requiring 25mm stacking height.
  • Designs needing up to 100 mating cycles.

QTH-060-07-L-D-A FAQs

7 frequently asked questions generated from this part’s specifications.
What is the pitch of the QTH-060-07-L-D-A?

The pitch is 0.50mm (0.0197").

How many positions does this connector have?

120 positions arranged in 2 rows.

What is the current rating per contact?

2 A per pin with 2 pins powered.

What is the voltage rating?

175 VAC at 5 mm stack height.

What is the mounting type?

Surface Mount.

What is the operating temperature range?

-55 °C to +125 °C.

What is the mated stacking height?

25mm.
