| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
120 pcs
|
120 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Features | |
| Halogen Free | |
| Height Above Board | |
| Lead Spacing | |
| Lead Style | |
| Mated Stacking Heights | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch | |
| SVHC Present |
The QTE-040-02-F-D-A is a high-density mezzanine connector from Samtec Inc. It is a header with outer shroud contacts, designed for board-to-board stacking applications. The connector features 80 positions arranged in 2 rows with a 0.80mm pitch, enabling compact and reliable interconnections.
This connector is surface mount compatible and has a height above board of 0.286 inches (7.26mm), with a mated stacking height of 8mm. The contacts are finished with gold, with a thickness of 3.00 microinches (0.076 micrometers), ensuring good conductivity and corrosion resistance. Additional features include a board guide for alignment and a ground bus plane for improved signal integrity.
The QTE-040-02-F-D-A is part of Samtec's QTE series, which are known for their high-speed performance and reliability in dense electronic assemblies. The connector is suitable for applications requiring a robust and space-saving board-to-board connection.
| Qty | Low | High |
|---|---|---|
| 1+ | $10.42 | $10.42 |
| 64+ | $8.01 | $8.01 |
| 128+ | $7.79 | $7.79 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
80 positions.
0.80mm (0.031 inches).
Surface mount.
Gold, with a thickness of 3.00 microinches (0.076 micrometers).
0.286 inches (7.26mm).
8mm.
Board guide and ground bus (plane).
