QSH-060-01-F-D-TR Samtec QSH-060-01-F-D-TR is a 120-position, 0.50mm pitch receptacle connector with center strip contacts, surface mount, gold plating, and a ground bus plane feature.
Mfr Part #:

QSH-060-01-F-D-TR

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec QSH-060-01-F-D-TR is a 120-position, 0.50mm pitch receptacle connector with center strip contacts, surface mount, gold plating, and a ground bus plane feature.
✓ Total Stock: 98 pcs
$ Price Range: $6.37

QSH-060-01-F-D-TR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Hybrid Electronics ✓
Non-Authorised Inventory information
98 pcs
On Request
98 pcs On Request 1 On Request On Request 11+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

QSH-060-01-F-D-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Features
Height Above Board
Lead Spacing
Lead Style
Mated Stacking Heights
Mounting Type
Number of Positions
Number of Rows
Pitch
SVHC Present
Tape & Reel
View Similar Products (0)

QSH-060-01-F-D-TR Description

Short technical summary and product information.

The Samtec QSH-060-01-F-D-TR is a high-density mezzanine (board-to-board) receptacle connector featuring 120 positions arranged in 2 rows with a 0.50mm (0.020") pitch. It is designed for surface mount soldering and includes a ground bus (plane) for improved signal integrity and reduced electromagnetic interference.



The connector has a height above board of 0.128" (3.25mm) and supports multiple mated stacking heights: 5mm, 8mm, 11mm, 14mm, 16mm, 19mm, and 25mm, offering flexibility in board spacing. Contacts are finished with 3.00µin (0.076µm) gold for reliable low-resistance connections.



This part is packaged in tape and reel (TR) for automated assembly. It is suitable for applications requiring dense, high-speed interconnections between parallel PCBs.

QSH-060-01-F-D-TR Quick Information

Product Type: Receptacle Connector
Series: QSH
Canonical Name: QSH-060-01-F-D-TR Receptacle, Center Strip Contacts, 120 Positions, 0.50mm Pitch, Surface Mount
Subcategory: Mezzanine (Board to Board) Connector

QSH-060-01-F-D-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

QSH-060-01-F-D-TR Estimated Pricing

Qty Low High
700+ $6.37 $6.37

Estimated market price range - modelled values for guidance only, not live distributor offers.

QSH-060-01-F-D-TR Features

  • 120 positions in 2 rows with 0.50mm pitch.
  • Surface mount termination for automated assembly.
  • Gold contact finish for reliable connections.
  • Ground bus plane for improved signal integrity.
  • Supports multiple mated stacking heights from 5mm to 25mm.

QSH-060-01-F-D-TR Applications

  • Board-to-board mezzanine stacking in compact electronics.
  • High-density interconnects for servers and networking gear.
  • Used in industrial control and test equipment.

QSH-060-01-F-D-TR FAQs

6 frequently asked questions generated from this part’s specifications.
How many positions does the QSH-060-01-F-D-TR have?

120 positions arranged in 2 rows.

What is the pitch of this connector?

0.50mm (0.020").

What mounting type does this connector use?

Surface mount.

What is the contact finish and thickness?

Gold with 3.00µin (0.076µm) thickness.

What mated stacking heights are supported?

5mm, 8mm, 11mm, 14mm, 16mm, 19mm, and 25mm.

Does this connector include a ground plane?

Yes, it features a ground bus (plane).
