The Qualtek QPS-35-24 is an open frame AC/DC converter designed for ITE (Commercial) applications. It provides a 36W power output with a single 24V output voltage and a current rating of 1.5A.
This converter operates with a universal input voltage range of 90 to 264 VAC, offering flexibility for global use. Key features include adjustable output and universal input capabilities. The efficiency is rated at 83%.
Designed for easy integration, the QPS-35-24 has a chassis mount type and dimensions of 101.6mm x 51.0mm x 25.1mm. It operates within a temperature range of -20°C to 65°C with derating. The isolation voltage is 3 kV, and it is approved by CB, CE, and cURus agencies.
The QPS-35-24 has a single output voltage of 24V.
The QPS-35-24 has a power rating of 36W.
The input voltage range is 90 to 264 VAC.
The QPS-35-24 uses chassis mount.
The operating temperature range is -20°C to 65°C, with derating.
The dimensions are 101.6mm in length, 51.0mm in width, and 25.1mm in height.
