| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage |
The Qualtek QPDF-150-48 is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It delivers 150W of power with a single 48VDC output and a maximum output current of 3.2A.
This converter operates with a universal AC input range of 85 to 264 VAC, offering flexibility in power sources. It boasts an efficiency of 87% and features like adjustable output, DC input capability, and active Power Factor Correction (PFC).
The unit is designed for chassis mounting and has dimensions of 194.0mm x 99.0mm x 50.0mm. It operates within a temperature range of -25°C to 70°C with derating and provides 3 kV of isolation voltage. Compliance includes RoHS3, REACH Unaffected, and MSL 1.
Key specifications include a 150W power rating, 48V output, 3.2A output current, and universal input voltage. The operating temperature range and chassis mount design make it suitable for various industrial and commercial environments.
The Qualtek QPDF-150-48 has a single output voltage of 48VDC.
The QPDF-150-48 converter has a power rating of 150W.
The Qualtek QPDF-150-48 accepts a universal input voltage range of 85 to 264 VAC.
The dimensions of the QPDF-150-48 are 194.0mm in length, 99.0mm in width, and 50.0mm in height.
The operating temperature range is -25°C to 70°C with derating.
Yes, the QPDF-150-48 is RoHS3 Compliant.
