The Qualtek QPD-75-24 is an enclosed AC/DC power supply designed for reliable power conversion. It delivers a single 24VDC output with a maximum power of 75W and a current rating of 3.2A.
This power supply operates with a universal AC input range of 88-264VAC, making it suitable for global applications. It boasts an efficiency of 87% and provides an isolation voltage of 3kV. The operating temperature range is -25°C to +70°C with derating.
Designed for chassis mounting, the QPD-75-24 has dimensions of 129.0mm x 99.0mm x 38.0mm. Key features include adjustable output, DC input capability, and universal input. It is approved by CB, CE, and cURus, indicating compliance with various safety standards for ITE (Commercial) applications.
24 VDC.
75W.
88-264 VAC.
-25°C to 70°C with derating.
Chassis mount.
