| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Qualtek QPD-15-3.3 is an enclosed frame AC/DC power supply designed for ITE (Commercial) applications. It delivers a continuous output power of 15W with a single output voltage of 3.3V and a maximum current of 4A.
This power supply accepts a universal AC input voltage range of 88-264VAC and features a no-load power consumption of less than 0.5W. It is designed for chassis mounting and includes features such as adjustable output, DC input capability, and universal input.
The operating temperature range is -20°C to +70°C, with derating potentially applied. The unit has an efficiency of 71% and an isolation voltage of 3kV. Conformal coating is applied to the PCB soldering side for added protection.
Key specifications include dimensions of 79.0mm x 50.4mm x 28.8mm. The QPD-15-3.3 is approved by CB, CE, and cURus agencies, indicating compliance with relevant safety standards.
The Qualtek QPD-15-3.3 has a single output voltage of 3.3 VDC.
The QPD-15-3.3 power supply has a power rating of 15W.
The maximum output current for the QPD-15-3.3 is 4 A.
The QPD-15-3.3 accepts a universal AC input voltage range of 88-264 VAC.
The dimensions of the QPD-15-3.3 are 79.0mm in length, 50.4mm in width, and 28.8mm in height.
The operating temperature range for the QPD-15-3.3 is -20°C to +70°C.
The QPD-15-3.3 supports chassis mount.
