The Mean Well QP-200D is an enclosed AC/DC converter with a power rating of 203.4W. It operates with an input voltage range of 90~264VAC and provides a nominal output voltage of 5V with a rated current of 15A. This model is designed for chassis mounting and features adjustable output, Active PFC for energy efficiency, and universal input capability.
The operating temperature range for the QP-200D is -10°C to 60°C, with derating applied. Its dimensions are 215.0mm in length, 115.0mm in width, and 50.0mm in height. The converter meets international energy efficiency standards and carries safety certifications including CB, CE, EAC, TÜV, and UL. It is backed by a 3-year warranty.
This power supply is suitable for ITE (Commercial) applications and offers features like PFC and remote sense. The unit is designed for reliable performance in various industrial environments.
The maximum output voltage of the Mean Well QP-200D is 5V.
The rated output current for the QP-200D is 15A.
The QP-200D operates between -10°C and 60°C, with derating.
The dimensions are 215.0mm in length, 115.0mm in width, and 50.0mm in height.
The QP-200D is certified by CB, CE, cURus, and TUV.
The QP-200D comes with a 3-year warranty.
