| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Dimensions | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Overload Protection | |
| Power (Watts) | |
| Power Rating | |
| Rated Current | |
| SVHC Present | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Mean Well QP-200-3A is an enclosed AC/DC converter designed for reliable power conversion. It offers a power rating of 200W and a primary output voltage of 5V, with a rated current of 15A. The unit accepts a universal AC input range of 90V to 264V, making it suitable for global applications.
Key electrical features include built-in active PFC with a power factor greater than 0.95, adjustable DC output range of ±10% for the main channels, and protections against short circuit, overload (110%-150%), and over-voltage (115%-135%). It operates with a fixed switching frequency of 100KHz and includes a built-in DC fan for cooling, allowing operation up to 60°C.
Designed for ease of integration, the QP-200-3A features a chassis mount and terminal block connections for both input and output. Its dimensions are 8.46 x 4.52 x 1.96 inches, weighing 2.64 lbs. The converter is built for high efficiency, long life, and high reliability, backed by a 3-year warranty.
The QP-200-3A has a primary output voltage of 5V.
The rated current for the QP-200-3A is 15A.
The QP-200-3A has a power rating of 200W.
The QP-200-3A accepts a universal AC input voltage range of 90V to 264V.
The QP-200-3A uses a chassis mount.
The operating temperature range for the QP-200-3A is -10°C to 60°C.
Yes, the QP-200-3A features a built-in active PFC function with a power factor greater than 0.95.
