| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Qualtek QGKF-320-24 is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It delivers a robust 320W of power with a single 24VDC output, capable of supplying up to 13A.
This converter operates with a universal AC input range of 85-264VAC, making it suitable for global use. Key electrical features include an efficiency rating of 87% and built-in Power Factor Correction (PFC). The unit provides 3 kV of isolation voltage.
Designed for chassis mounting, the QGKF-320-24 has dimensions of 199.0mm x 99.0mm x 50.0mm. It operates within a temperature range of -25°C to 70°C with derating. The product is RoHS3 Compliant and has an MSL rating of 1.
The QGKF-320-24 provides a fixed 24VDC output voltage.
It accepts a universal input voltage range of 85 to 264 VAC.
The unit ships in a bulk package configuration.
The converter operates reliably up to 70°C with derating applied at higher temperatures.
The device features a 3 kV isolation voltage rating.
Yes, the unit is capable of accepting DC input signals.
