| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Qualtek QGKF-240-5 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers 240W of power with a single 5V output and a maximum current of 48A.
This converter operates with a universal AC input range of 85 to 264 VAC and boasts an efficiency of 79%. Key features include adjustable output, DC input capability, Power Factor Correction (PFC), and universal input. The isolation voltage is rated at 3 kV.
With a chassis mount type, the QGKF-240-5 has dimensions of 199.0mm x 99.0mm x 50.0mm. It operates within a temperature range of -25°C to 70°C (with derating). The unit is RoHS3 compliant, has an MSL of 1 Unlimited, and is REACH Unaffected.
85 to 264 VAC.
5V at 48A.
240W.
-25°C to 70°C with derating.
Enclosed chassis mount.
CB, CE, and cURus.
79%.
