| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Dimensions | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Storage Temperature | |
| Topology | |
| Voltage | |
| Voltage Range | |
| Weight | |
| Width |
This Qualtek QFWB-65-24-US01 is a 65-watt single output AC/DC power adapter designed for wall mounting. It features a universal AC input range of 100-240VAC and operates at 50-60Hz.
The adapter provides a stable 24V DC output at a rated current of 2.7A. It is designed with efficiency in mind, meeting the Level VI energy efficiency standard. Protections include short circuit and over current.
Key electrical specifications include a 1.5A maximum AC current draw and a low no-load power consumption of less than 0.1W. The operating temperature range is from 0°C to 40°C.
Mechanically, the unit measures 117.3mm x 50.3mm x 33.5mm and weighs 300g. It utilizes a NEMA 1-15P input connector for North American outlets and a standard barrel plug output connector (2.1mm I.D. x 5.5mm O.D.). The cord length is approximately 1.20 meters.
The QFWB-65-24-US01 provides a 24V DC output at a rated current of 2.7A.
This adapter has a power rating of 65 Watts.
The adapter meets the Level VI energy efficiency standard.
The operating temperature range for this adapter is 0°C to 40°C.
It uses a NEMA 1-15P input connector, suitable for North America.
The output connector is a Barrel Plug with a 2.1mm I.D. and 5.5mm O.D.
Yes, it includes Short Circuit and Over Current protection.
