The Qualtek QFWB-30-5-US01 is a versatile AC/DC wall mount adapter designed for commercial ITE applications. It delivers a stable 5V output with a maximum current of 3.5A, providing up to 18W of power.
This adapter meets Level VI efficiency standards, ensuring optimal energy usage. It features a NEMA 1-15P input connector for North American regions and a standard 2.1mm I.D. x 5.5mm O.D. barrel plug output with a 11.0mm length. The cord length is approximately 59 inches (1.50m).
Designed with a positive center polarization, the QFWB-30-5-US01 operates within a temperature range of 0°C to 40°C. Its compact dimensions (71.3mm x 43.3mm x 28.8mm) and wall mount form factor make it suitable for various integration needs. The adapter also boasts a low no-load power consumption of 100mW maximum.
Compliance includes cULus approval, RoHS3 compliance, and REACH unaffected status. The Moisture Sensitivity Level (MSL) is rated at 1 Unlimited.
The QFWB-30-5-US01 has an output voltage of 5V and a maximum output current of 3.5A.
The QFWB-30-5-US01 adapter has a power rating of 18W.
The QFWB-30-5-US01 meets Level VI efficiency standards.
The adapter operates within a temperature range of 0°C to 40°C.
The QFWB-30-5-US01 uses a NEMA 1-15P input connector.
The output connector is a Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11.0mm.
Yes, the QFWB-30-5-US01 is RoHS3 Compliant.
