QFWB-20-9 The Qualtek QFWB-20-9 is an 18W AC/DC wall mount adapter providing a 9V output. It features a fixed blade input and is designed for ITE (Commercial) applications.
Mfr Part #:

QFWB-20-9

Mfr Name: Qualtek
Qualtek
The Qualtek QFWB-20-9 is an 18W AC/DC wall mount adapter providing a 9V output. It features a fixed blade input and is designed for ITE (Commercial) applications.
Stock on Request

QFWB-20-9 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Cord Length
Current
Efficiency
Form
Input Connector
Input Type
No Load Power Consumption
Operating Temperature
Power (Watts)
Region Utilized
SVHC Present
Voltage
View Similar Products (0)

QFWB-20-9 Description

Short technical summary and product information.

The Qualtek QFWB-20-9 is an AC/DC external wall mount adapter with a 9V output and a maximum power rating of 18W. It operates with an input voltage range of 100 to 240 VAC and achieves Level VI efficiency.



Designed for ITE (Commercial) applications, this adapter features a NEMA 1-15P input connector and a fixed blade input type. Its compact dimensions are 59.0mm x 40.9mm x 26.5mm, making it suitable for various installations. The operating temperature range is from 0°C to 40°C.



This Class II wall mount adapter comes with a cord length of 59 inches (1.50m) and has a low no-load power consumption of 100mW. It is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1 Unlimited. The adapter is approved by cULus and FCC.

QFWB-20-9 Quick Information

Product Type: AC DC Desktop, Wall Adapter
Series: QFWB-20
Canonical Name: Qualtek QFWB-20-9 AC/DC Wall Mount Adapter
Subcategory: Power Supplies

QFWB-20-9 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

QFWB-20-9 Features

  • 18W AC/DC wall mount adapter
  • 9V output voltage
  • 100-240 VAC input voltage
  • Level VI efficiency rating
  • NEMA 1-15P input connector

QFWB-20-9 Applications

  • Powers commercial information technology equipment.
  • Suitable for networking devices like routers and switches.
  • Ideal for point-of-sale terminals and kiosks.
  • Used in security camera systems and access control.
  • Provides reliable power for small office equipment.

QFWB-20-9 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the output voltage of the QFWB-20-9 adapter?

The output voltage is 9V.

What is the maximum output current for the QFWB-20-9?

The maximum output current is 2A.

What is the power rating of the Qualtek QFWB-20-9 adapter?

The power rating is 18W.

What is the input voltage range for the QFWB-20-9?

The input voltage range is 100 to 240 VAC.

What is the efficiency level of the QFWB-20-9 adapter?

The efficiency level is VI.

What are the dimensions of the QFWB-20-9 adapter?

The dimensions are 59.0mm x 40.9mm x 26.5mm.

What is the operating temperature range for this adapter?

The operating temperature range is 0°C to 40°C.
