| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Operating Temperature | |
| Power (Watts) | |
| Region Utilized | |
| Voltage | |
| Voltage Range | |
| Weight | |
| Width |
The Qualtek QFWB-20-5-US01 is an AC/DC wall mount adapter designed for commercial ITE applications. It provides a stable 5V output with a maximum current of 3A, delivering a total power of 15W. This adapter meets the Level VI energy efficiency standard, ensuring reduced power consumption.
With a universal input voltage range of 100-240 VAC and a frequency range of 50-60 Hz, it is suitable for use in North America. The adapter features a fixed blade input connector (NEMA 1-15P) and a compact, wall-mountable (Class II) form factor. Its dimensions are 59.0mm x 40.9mm x 26.5mm, and it weighs 87g. The operating temperature range is from 0°C to 40°C.
Compliance includes FCC Part 15 Class B for EMI/RFI, and it adheres to harmonic current and EMS immunity standards. The adapter also boasts a Mean Time Between Failures (MTBF) of 50,000 hours at 25°C.
The output voltage is 5V DC.
The input voltage range is 100-240VAC at 50-60Hz.
The adapter is wall mount (Class II).
The operating temperature range is 0°C to 40°C.
The output current rating is 3A.
It meets Level VI efficiency standards.
The dimensions are 59.0mm x 40.9mm x 26.5mm.
