| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Input Connector | |
| Input Type | |
| No Load Power Consumption | |
| Operating Temperature | |
| Power (Watts) | |
| Region Utilized | |
| SVHC Present | |
| Voltage |
The Qualtek QFWB-20-5 is an AC/DC wall mount adapter designed for commercial ITE applications. This adapter provides a stable 5V output with a maximum current of 3A, delivering a total power of 15W. It meets Energy Efficiency Level VI standards and operates with an input voltage range of 100 to 240 VAC.
The adapter features a fixed blade input and a NEMA 1-15P connector, suitable for North American regions. Its compact dimensions (59.0mm x 40.9mm x 26.5mm) make it convenient for various setups. The operating temperature range is from 0°C to 40°C, and it has a low no-load power consumption of 100mW.
Designed as a Class II adapter, the QFWB-20-5 is suitable for use in commercial environments. It comes in a bulk package and is RoHS3 Compliant.
The QFWB-20-5 adapter has an output voltage of 5V and a maximum output current of 3A.
The QFWB-20-5 adapter has a power rating of 15W.
The input voltage range for the QFWB-20-5 adapter is 100 to 240 VAC.
The QFWB-20-5 adapter meets Energy Efficiency Level VI.
The dimensions of the QFWB-20-5 adapter are 59.0mm in length, 40.9mm in width, and 26.5mm in height.
The operating temperature range for the QFWB-20-5 adapter is 0°C to 40°C.
