Mfr Part #:

QFWB-20-36

Mfr Name: Qualtek

The Qualtek QFWB-20-36 is a 20W AC/DC wall mount adapter providing a 36V output. It features Level VI efficiency and a NEMA 1-15P input connector.

Stock on Request

QFWB-20-36 Description

Short technical summary and product information.

This Qualtek QFWB-20-36 is an AC/DC wall mount adapter designed for commercial ITE applications. It delivers a 36V output at a maximum current of 550mA, with a total power rating of 20W. The adapter meets Level VI efficiency standards and operates with an input voltage range of 100-240 VAC.

Featuring a fixed blade input and a NEMA 1-15P connector, the QFWB-20-36 also includes a standard 2.5mm I.D. x 5.5mm O.D. barrel plug output. Its compact dimensions of 59.0mm x 40.9mm x 26.5mm make it suitable for various space-constrained designs. The operating temperature range is 0°C to 40°C.

Compliance includes RoHS3, REACH Unaffected, and Moisture Sensitivity Level 1. Approval agencies for this adapter are cULus and FCC. The cord length is 1.50 meters.

QFWB-20-36 Quick Information

Product Type: AC DC Desktop, Wall Adapter

Canonical Name: Qualtek QFWB-20-36 AC/DC Wall Mount Adapter

Subcategory: AC/DC Adapter

QFWB-20-36 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

QFWB-20-36 Features

20W AC/DC wall mount adapter.
36V output voltage.
550mA maximum output current.
Level VI efficiency rating.
NEMA 1-15P input connector.

QFWB-20-36 Applications

Suitable for ITE commercial applications.
Designed for wall mount installations.
Provides stable 36V DC power.
Compact form factor for integration.

QFWB-20-36 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the output voltage of the Qualtek QFWB-20-36 adapter?

The output voltage is 36V.

What is the maximum output current for the QFWB-20-36?

The maximum output current is 550mA.

What is the power rating of the Qualtek QFWB-20-36 adapter?

The power rating is 20W.

What efficiency level does the QFWB-20-36 meet?

It meets Level VI efficiency.

What is the operating temperature range for this adapter?

The operating temperature range is 0°C to 40°C.

What type of input connector does the QFWB-20-36 use?

It uses a NEMA 1-15P input connector.

What is the output connector type and size?

The output connector is a Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm.

Category	AC DC Desktop, Wall Adapters
Manufacturer Name	Qualtek
AEC Qualified	No
Applications	ITE (Commercial)
Approval Agency	cULus, FCC
Automotive Grade	No
Cord Length	1.50m (59")
Current	550mA
Duration	59.0mm x 40.9mm x 26.5mm (2.32" L x 1.61" W x 1.04" H)
Efficiency	Level VI
Form	Wall Mount (Class II)
Height	26.5mm (1.04")
Industrial Grade	No
Input Connector	NEMA 1-15P
Input Type	Fixed Blade
Input Voltage	100 ~ 240 VAC
Length	59.0mm (2.32")
Medical Grade	No
Military Grade	No
Mounting Type	Wall Mount
No Load Power Consumption	100mW
Operating Temperature	0°C ~ 40°C
Output Connector	Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Power (Watts)	20 W
Region Utilized	North America
Voltage	36V
Width	40.9mm (1.61")
