The Qualtek QFWB-20-24 is an AC/DC external wall mount adapter designed for commercial ITE applications. This adapter delivers a stable 24V output with a maximum current of 830mA, providing a total power of 20W. It features a fixed blade input connector (NEMA 1-15P) and operates within a universal input voltage range of 100 to 240 VAC.
Designed for efficiency, the QFWB-20-24 meets Level VI efficiency standards and has a low no-load power consumption of 100mW. Its compact dimensions measure 59.0mm x 40.9mm x 26.5mm, making it suitable for various space-constrained applications. The operating temperature range is from 0°C to 40°C.
This Class II adapter is approved by cULus and FCC, ensuring compliance with safety and regulatory standards. It is packaged in bulk and is suitable for use in North America.
The QFWB-20-24 adapter provides a 24V output voltage and a maximum output current of 830mA.
The QFWB-20-24 adapter has a power rating of 20W.
The QFWB-20-24 adapter accepts an input voltage range of 100 to 240 VAC.
The QFWB-20-24 adapter meets Level VI efficiency standards.
The QFWB-20-24 adapter operates within a temperature range of 0°C to 40°C.
The QFWB-20-24 adapter uses a NEMA 1-15P input connector.
The QFWB-20-24 adapter is supplied in bulk packaging.
