| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
220 pcs
|
220 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Plating | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Temperature Rating | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The PZC36DAFN is a 72 position dual row unshrouded header from Sullins Connector Solutions. It features a 2.54mm pitch and is designed for through hole mounting with solder termination. The header is suitable for board-to-board or cable-to-board applications.
Electrical ratings include a current rating of 3A and a voltage rating of 600VDC at sea level. Insulation resistance is 5000 MΩ. The contact material is phosphor bronze (CA510) with gold plating on the heads (10µin), tin on the tails (100µin), and nickel underplate (50µin). The insulator is black thermoplastic polyester with a UL94 V-0 flammability rating.
The header operates continuously up to 125°C. The overall contact length is 0.950" (24.13mm) with a contact length of 0.620" (15.75mm). Row spacing is 0.100" (2.54mm). The push-pull fastening type allows easy mating and unmating.
| Qty | Low | High |
|---|---|---|
| 250+ | $3.34 | $3.34 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The header has 72 positions arranged in 2 rows.
The pitch is 2.54mm (0.100").
The current rating is 3A.
The voltage rating is 600VDC minimum at sea level.
The mounting type is through hole with solder termination.
Contact material is phosphor bronze (CA510). Plating is 10µin gold on heads, 100µin tin on tails, with 50µin nickel underplate.
The header operates continuously up to 125°C.
