PZ3D4V2H The PRISEMI PZ3D4V2H is a TVS Diode with a nominal Zener voltage of 150V and a power dissipation of 3W. It is supplied in an SMA package.
Mfr Part #:

PZ3D4V2H

Available from 2 distributors
Mfr Name: Prisemi
Prisemi
The PRISEMI PZ3D4V2H is a TVS Diode with a nominal Zener voltage of 150V and a power dissipation of 3W. It is supplied in an SMA package.
✓ Total Stock: 4,581 pcs

PZ3D4V2H Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
3,314 pcs
On Request
3314 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
1,267 pcs
On Request
1267 pcs On Request 1 On Request On Request 14+15+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PZ3D4V2H Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Lead Style
Package / Case
Power Dissipation
Reverse Voltage
SVHC Present
View Similar Products (0)

PZ3D4V2H Description

Short technical summary and product information.

The PRISEMI PZ3D4V2H is a TVS (Transient Voltage Suppressor) Diode designed for circuit protection. It features a nominal Zener voltage of 150V and a maximum power dissipation of 3W.



This diode has a typical Zener impedance of 600 Ohms at 2.5mA and a reverse leakage current of 1μA at 114V. The component is housed in an SMA package, suitable for surface mounting.



Applications for this TVS diode include protecting sensitive electronic components from voltage transients in various systems. Its specifications make it suitable for use in power supplies, communication equipment, and consumer electronics where overvoltage protection is critical.

PZ3D4V2H Quick Information

Product Type: TVS Diode
Canonical Name: PRISEMI PZ3D4V2H Zener Diode
Subcategory: TVS Diodes

PZ3D4V2H Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PZ3D4V2H Features

  • 150V typical Zener voltage rating.
  • 3W power dissipation capability.
  • Low reverse leakage current of 1μA.
  • SMA surface-mount package.
  • Tested at 2.5mA Zener current.

PZ3D4V2H Applications

  • Protects sensitive electronic circuits.
  • Used in power supply applications.
  • Suitable for communication equipment.
  • Ideal for consumer electronics.

PZ3D4V2H FAQs

6 frequently asked questions generated from this part’s specifications.
What is the typical Zener voltage of the PZ3D4V2H?

The typical Zener voltage is 150V at a test current of 1mA.

What is the power dissipation rating of the PZ3D4V2H?

The power dissipation is 3W.

What package is the PZ3D4V2H available in?

The device is available in an SMA package.

What is the maximum reverse leakage current?

The maximum reverse leakage current is 1μA at a reverse voltage of 114V.

What is the Zener impedance at the test current?

The Zener impedance is 600Ω at 2.5mA.

What is the Zener test current?

The Zener test current is 2.5mA.
